Sunlight Exposure Chamber

The features of our SEC Series Sunlight Exposure Chamber.Sunlight Exposure Chamber or aging test chamber is used to test for property changes of materials caused by sunlight, temperature and moisture in a short period of time. Product changes happening outdoor or indoor over months or years, such as fading, yellowing or embrittlement can often be simulated within weeks inside a SUNTEST. This Chamber gives Premium simulation of solar radiation according to CIE85 reference sun, Optional simulation of window glass filtered daylight, and others, Automatic control of irradiance for various testing needs.This is extremely valuable for manufacturers who want to determine optimal performance during warranty periods, expected lifecycle of products, and the proper levels of UV inhibitors to include in their manufacturing processes.Customers can select optimal model for their needs based on performance and test area capacity.A benefit of this SEC Series Sunlight Exposure Chamber is, it comes with an unconditional 2 years warranty.

Control Instrumentation- HMI Red Lion & Siemens (PLC)

Red Lion (HMI) & Siemens (PLC) or Eurotherm. This chamber comes with two controllers, it’s the choice of the customer if they want HMI or Eurotherm. For HMI 7” Red Lion high resolution TFT provided with program logic controller (Siemens). Number of programs & profile segments with ramp & soak duration provided for cyclic operation. The temperature measuring and control systems provided with PID modules. Set value & process value with graphical display on main screen.

Control Instrumentation -Eurotherm Programmer

Eurotherm (UK make) Programmable microprocessor PID controller for temperature with digital display powerful PID, no of programs & segments each could be stored in ramp & soak period settable in hours & minutes. No of loops provided for re-appear the program. Control readout of actual and set-point values & calibration capability for actual and set values. PC communication with user friendly software. RS 232/485 communication port provided for operating the chamber through PC as well as data logging facility. Tubular display & graphical display provided with complete history printing & storing facility.

Refrigeration system

Single or Cascade system. Compressors:Bitzer/GEA Hermetic or semi hermetic. Sealed compressor will be provided for low temperature. The compressor used in the system is Emerson. Liquid receiver &Filter (Danfoss-Denmark), wellbalanced Hi cool(CE approvedCondenserfanwithsafety grill)

Components

Danfoss, Bitzer, GEA, Henry, ABB, Siemens, Hager, Honeywell, Wika, TAIE, EYC etc.
