Flame Proof and Explosion Proof Test Chamber

Flameproof and Explosion Proof Test Chamber is designed as per the IEC Standards IEC60068, MIL & JSS55555.The features of our FEC Series Flame Proof and Explosion Chamber. Flameproof and Explosion Proof Chambers are built with highest quality and reliability. Flameproof and Explosion Proof Chambers realistically simulates the environment according to temperature and humidity.Flame proof chambers are needed for storage of aerosol, volatile, flammable liquids, reagents, chemicals and organic solvents, that meet all criteria. This chamber is designed as per the Global standard for communication protocol This Chamber can meet the most stringent testing needs of various international standards.This Chamber provides explosion proofing to all interior components of the chambers including light fittings, Motors, Control Panel, HMI, Sensors. Temperature can be customised according to customers need. The size of the chamber is customer-specific and process-integrated systems, with the latest technology. Customers can select optimal model for their needs based on performance and test area capacity. A benefit of this FEC Series Flame Proof and Explosion Proof Test Chamber is, it comes with an unconditional 2 years warranty.

Control Instrumentation- HMI Red Lion & Siemens (PLC)

Red Lion (HMI) & Siemens (PLC) or Eurotherm. This chamber comes with two controllers, it’s the choice of the customer if they want HMI or Eurotherm. For HMI 7” Red Lion high resolution TFT provided with program logic controller (Siemens). Number of programs & profile segments with ramp & soak duration provided for cyclic operation. The temperature measuring and control systems provided with PID modules. Set value & process value with graphical display on main screen.

Control Instrumentation -Eurotherm Programmer

Eurotherm (UK make) Programmable microprocessor PID controller for temperature withdigital display powerful PID, no of programs & segments each could be stored in ramp &soak period settable in hours & minutes. No of loops provided for re-appear the program. Control readout of actual and set-point values & calibration capability for actual and set values. PC communication with user friendly software. RS 232/485 communication port provided for operating the chamber through PC as well as data logging facility. Tubular display & graphical display provided with complete historyprinting & storing facility.

Refrigeration system

Single or Cascade system. Compressors:Bitzer/GEA Hermetic or semi hermetic. Sealed compressor will be provided for low temperature. The compressor used in the system is Emerson. Liquid receiver &Filter (Danfoss-Denmark), wellbalanced Hi cool(CE approved Condenser fan with safety grill)

Port

Holes, shelves and trays as per the requirement

Components

Danfoss, Bitzer, GEA, Henry, ABB, Siemens, Hager, Honeywell, Wika,TAIE, EYC etc.
