Arabidopsis Plant Growth Chamber Walk in Plant Growth Chamber

Short Plant growth chambers and rooms are specifically designed to maximize growth area by incorporating a multi-tier shelf design. They are ideal for genetic studies involving Arabidopsis, plant physiology, and early growth studies of seedlings.Kelviron’s plant growth chambers are specifically designed with two separate plant growth compartments with independent control of environmental parameters enabling two experiments to be conducted simultaneously. The chamber features an open channel floor delivering upward airflow providing uniform conditions on a horizontal plane. The electrical and refrigeration systems are located at waist height with ease of service in mind. This plant growth chamber provides tight uniform control of temperature, a balanced lighting spectrum using a mixture of fluorescent and halogen lamps, and adjustable airflow. Plant Growth Chambers are a stock design with a variety of customizable options. They are quiet, easy to clean, highly reliable and ideal for plant growth use. They offer hot gas bypass control of refrigeration and resistance to heat, to facilitate reliable, temperature and optional humidity control.Plant Growth Chambers are our new innovation, where you experience uncompromising performance guarantee through stringent temperature, light and humidity control. Customers can select optimal model for their needs based on performance and test area capacity.Each Walk in Chamber is tested at the factory to meet your test specifications. A benefit of this PGC Series Arabidopsis Plant Growth Chamber Walk in Plant growth chamber is, it comes with an unconditional 2 years warranty.

Plant Growth Chamber Manufacturers Control Instrumentation- HMI Red Lion & Siemens (PLC)

Red Lion (HMI) & Siemens (PLC) or Eurotherm. This chamber comes with two controllers, it’s the choice of the customer if they want HMI or Eurotherm. For HMI 7” Red Lion high resolution TFT provided with program logic controller (Siemens). Number of programs & profile segments with ramp & soak duration provided for cyclic operation. The temperature measuring and control systems provided with PID modules. Set value & process value with graphical display on main screen.

Control Instrumentation -Eurotherm Programmer

Eurotherm (UK make) Programmable microprocessor PID controller for temperature with digital display powerful PID, no of programs & segments each could be stored in ramp & soak period settable in hours & minutes. No of loops provided for re-appear the program. Control readout of actual and set-point values & calibration capability for actual and set values. PC communication with user friendly software. RS 232/485 communication port provided for operating the chamber through PC as well as data logging facility. Tubular display & graphical display provided with complete history printing & storing facility.

Refrigeration system

Single or Cascade system. Compressors:Bitzer/GEA Hermetic or semi hermetic. Sealed compressor will be provided for low temperature. The compressor used in the system is Emerson. Liquid receiver &Filter (Danfoss-Denmark), wellbalanced Hi cool(CE approvedCondenserfanwithsafety grill)

Components

Danfoss, Bitzer, GEA, Henry, ABB, Siemens, Hager, Honeywell, Wika, TAIE, EYC etc.
